It is a sensor with built-in GPS that can obtain and display positioning data on the LoRa and the application platform. It is suitable for tracking assets, pets or people. With a built-in large-capacity battery, it has a long service life and meets various application requirements.
Product features
LoRa Technology Long range transmission High GPS accuracy Frequency range:863~928MHz 2 bi-color LEDs for status indication Panic button for emergency Buzzer and vibrator - 3 axis G-sensor (optional)
TLM932 V2 is a GPS tracking module which adopts low power, long range and wide area transmission LoRaTM technology.
TLM932 V2 integrates LoRa"s advantages and the low power GPS module to target on tracking and tracing the objectives, i.e. vehicles, pets, human beings and any other things that you would like to know the position.
TLM932 V2"s excellent GPS coverage and long range RF performance could be used for various kind of applications and alsohelp you easily find the position of the objectives on the APP.
Specification
Parameter
Value
Transceiver
Kiwi TLM922S LoRa Module
Frequency
863~928
Power supply
DC 5V/0.5A (micro-USB connector)
Battery Power
Lithium-ion, 920mAh
GPS Receiver
MTK 333X
G-Sensor
3-Axis G-Sensor (optional)
Acquisition Time
Hot start (Open Sky)
1s (typical)
Cold Start (Open Sky)
34s (typical) without AGPS
Transmission Power
+2~+20dBm
Data Rate
0.292~21.875Kbps (LoRa)
Sensitivity
Up to -137 dBm
Operation Temp.
0~+40 °C
Storage Temp.
-40~+50 °C
Dimension
80mmx40mmx20mm
We offered a completed model list for your various applications.
Model
Description
TLM932V2-GT
GPS Tracker2.0, GNSS, 920~925, TWN
TLM932V2-GS
GPS Tracker2.0, GNSS, 920~925, Singapore
TLM932V2-NJ
GPS Tracker2.0, Non-GNSS, 920~928, JPN
TLM932V2-NU
GPS Tracker2.0, Non-GNSS, 902~928, USA
TLM932V2-GE
GPS Tracker2.0, GNSS, 863~870, EU
TLM932V2-GI
GPS Tracker2.0, GNSS, 923~925, Indonesia
TLM932V2-GL
GPS Tracker2.0, GNSS, 920~925, Thailand
TLM932V2-GA
GPS Tracker2.0, GNSS, 915~928, Australia
TLM932V2-GD
GPS Tracker2.0, GNSS, 865~867, India
Application
Health care centerSchool SafetyOutdoor exercise safetyTouristTruck trackingPet tracking
