USB 3.0 CYUSB3014 development board FPGA Artix 7 A7 core board XC7A35T DDR3

modname=ckeditor
Main characteristic parameters of CYUSB3014 XC7A35T development board
1.USB3.0 main control chip:CYUSB3014-BZXG;
2.USB3.0 master chip external clock source frequency:19.2MHz;
3.CYUSB3014 chip comes with:512KB of SRAM;
4.CYUSB3014 chip comes with:ARM926EJ core running at 200MHz;
5.CYUSB3014 development board comes with W25064 SPI Flash chip, 8MB bytes of storage capacity;
6.CYUSB3014 development board comes with 5V to 3.3V DC/DC, the chip model is:MP2315;
7.CYUSB3014 development board comes with a 3.3V to 1.2V chip core voltage DC/DC, the chip model is:NCP1529;
8. CYUSB3014 development board leads to USB 3.0 Type-B female socket
9.FPGA chip:Xil inx Artix-7 XC7A35T-1FTG256C
10. FPGA chip external clock:50MHz:
11. The FPGA chip is configured with SPI Flash using MT250L128A, with a storage capacity of 16MB bytes;
12. Connect the FPGA chip to Micron 512MB DDR3 memory:MT41K256M16TW-107:P;
13. Development board size:83.8mm x 83.8mm;
